ARTEK MQB Rear Light Weight Sub Frame
$1,399.00
Fitment:
Audi TTRS 2018+
Audi RS3 2018+
Audi S3 8V
VW Golf GTI MK7
VW Golf R MK7
CARB And / Or EPA Compliance Testing Not Completed
ARTEK offers a wide range of performance road car product upgrades, information can be found on the different products by using the links below, further links for information can be found using the drop down menus on the navigation bar at the top of each page.
This product offers a complete bolt-in tubular subframe solution tailored for the VW MQB platform.
After long CAD development based on 3D scan of OEM subframe, tested with CAD CFD and road going tests you can now buy brand new, rust free, subframe for front of your MQB platform viechle.
Using same 4130 tubing as in CEC cars, our subframes provide increased stiffness and mass reduction. Additional the design enables better access to the car under body. All factory parts bolt up to this unit, no modifications are necessary.
What is included:
–rear subframe painted black
Notice: Sold for off road, track and racing applications only. We strongly advice to mount the subframe in qualified and experienced workshop that would know what are doing.
Features:
- Weight: 11.5KG
- Material: Steel Tubing, seeless, 4130
Properties:
- Tensile strength: 862 MPa
- Yield strength at 0.2% offset: 689 MPa
- Elongation in 2 inches: 12%
- Full Elongation in 2 inches, tube strip: 7%
This subframe does not include the differential. Please contact us before placing your order and we can make arrangements to satisfy your needs.
This tubular subframe significantly enhances the strength and rigidity of the suspension system while reducing overall weight.
Perfect OEM Fitment,directely replace the factory sub frame.
